Alpha ALPHA6000 Series - P2: Auxiliary Operation

Chapter 4 Parameter Index
http://www.acdrive-china.com
66
Function
code
Function
Name
LCD
Display
Range of settings
Default Change
MODBUS
Address
Brake
voltage
level
setting
(3004GB
or below)
Brake
voltage
level
setting
360～750V
1AC:
380V
3AC:
700V
P1.14
Brake
utility rate
(35R5G
B/37R5P
B or
above)
Brake utility
rate
0.0～100.0%
Note: Build-in is
active only for the
model of ac drive of
15kW or below of
this series,
Dynamic braking
takes effect
automatically during
deceleration
100.0%
× 020E
P1.15
Trip-free
treatment
Trip-free
treatment
0:once trip-free,
report Uu1 fault
1:In trip-free time
give
Uu alarm,
otherwise
report Uu1 fault
2:once trip-free, give
Uu alarm
0
× 020B
P1.16
Trip-free
time
Trip-free
time
0.5～10.0s
This
value
depend
s on the
ac drive
model.
× 0210
P2: Auxiliary Operation
Function
code
Function
Name
LCD Display
Range of
settings
Default Change
MODBUS
Address
P2.00
Jog
frequency
Jog
frequency
0.10 ～ Upper
limit
frequency
5.00Hz
○ 0300
