Chapter 4 Parameter Index
http://www.acdrive-china.com
65
Function
code
Function
Name
LCD
Display
Range of settings
Default Change
MODBUS
Address
P1.06
Time of
S-curve
initial
Time of
S-curve
initial
10.0～50.0%
(Acc/Dec Time)
P1.06+P1.07≤90%
20.0%
○ 0206
P1.07
Time of
S-curve
rising
Time of
S-curve
rising
10.0～80.0%
(Acc/Dec Time）
P1.06+P1.07≤90%
60.0%
○ 0207
P1.08
Stop
mode
Stop
mode
0: Deceleration to
stop
1: Coast to stop
2: Dec +DC braking
0
× 0208
P1.09
DC
injection
braking
frequenc
y at stop
DC
injection
braking
frequency
at stop
0.00～
MIN(50.00Hz,
Frequency upper
limit)
0.00Hz
○ 0209
P1.10
DC
injection
braking
waiting
time at
stop
DC
injection
braking
waiting
time at
stop
0.00～10.00s
0.00s
○ 020A
P1.11
DC
braking
current at
stop
DC
injection
braking
current at
stop
This value depends
on the ac drive model
Type G: 0.0～
100.0% (ac drive
rated current)
Type P: 0.0～80.0%
(ac drive rated
current)
0.0%
○ 020B
P1.12
DC
braking
time at
stop
Braking
time at
stop
0.0～30.0s
0.0s
○ 020C
P1.13
Dynamic
braking
selection
Dynamic
braking
selection
0: Dynamic braking
is disabled
1: Dynamic braking
is enabled
1
× 020D
