Alpha ALPHA6000 Series - Page 73

Chapter 4 Parameter Index
http://www.acdrive-china.com
73
This page only for 3004GB and below
Function
code
Function
Name
LCD
Display
Range of settings Default Change
MODBUS
Address
P3.03
Multi-fun
ction
input
selection
Terminal
X3
Terminal
X3
function
40: EI1: External
interrupt signal
normally close
41: Reserved
42: Start PLC
operation
43: Pause the PLC
operating
44: Reset PLC stop
status
45: Start Wobble
frequency
operating
46: Reset the Wobble
frequency
operating status
47: Start PID
operation
48:Reserved
49: Timing drive
input
50: Counter trig
signal input
51: Counter clear
52: Actual Length
clear
53: Timing units
chose
37 × 0403
P3.04
Multi-fun
ction
input
selection
Terminal
X4
Terminal
X4
function
0～53: Ibid
54: PUL: Pulse input
( If have 2 signals
input, follow X4)
55: Single-phase
speed measuring
input ( If have 2
signals input,
follow X4)
0 × 0407
