Chapter 4 Parameter Index
http://www.acdrive-china.com
74
This page only for 3004GB and below
Function
code
Function
Name
LCD
Display
Range of settings Default
Change
MODBUS
Address
P3.05
Multi-fun
ction
input
selection
Terminal
X5
Terminal
X5
function
56: Speed measuring
input SM1(only
for X4)
57: Speed measuring
input SM2(only
for X5)
0 × 0408
P3.06 Reserved Reserved Reserved 0 × 0406
P3.07 Reserved Reserved Reserved 0 × 0407
P3.08 Reserved Reserved Reserved 0 × 0408
P3.09
Operatio
n mode
setup
Operatio
n mode
setup
0: 2-wire control
mode1
1: 2-wire control
mode 2
2: 3-wire control
mode 1-self-hold
function (added
any terminal of
X1-X5)
3: 3-wire control
mode 2-self-hold
function (added
any terminal of
X1-X5)
0 × 0409
