Chapter 4 Parameter Index
http://www.acdrive-china.com
75
This page only for 35R5GB/37R5PB and over
Function
code
Function
Name
LCD
Display
Range of settings Default Change
MODBUS
Address
P3.00
Terminal
function
mode
Termin
al
functio
n mode
0: Close valid
1: Open valid
(Normally open
/close is not limited.)
0 × 0400
P3.01
Multi-fu
nction
input
selection
Terminal
X1
Termin
al X1
functio
n
1 × 0401
P3.02
Multi-fu
nction
input
selection
Terminal
X2
Termin
al X2
functio
n
0:NULL, No defined
1: FWD: Running
Forward
2: REV: Running
Reverse
3: RUN
4: F/R running direction
5: HLD self-hold
selection
6: RST reset
7: FC Setting frequency
selection
8: FJOG(JOG FWD)
9: RJOG(JOG REV)
10: UP 11:DOWN
12: UP/DOWN Reset
13: FRE Coast-to-stop
14: Forced outage
(According to Dec
time4)
15: DC injection
braking
16: Acc/Dec prohibit
17: Ac drive running
prohibit
18: S1 Multi-step
Speed 1
19: S2 Multi-step Speed
2
20: S3 Multi-step Speed
3
21: S4 Multi-step Speed
4
2 × 0402
