Alpha ALPHA6000 Series - Page 76

Chapter 4 Parameter Index
http://www.acdrive-china.com
76
This page only for 35R5GB/37R5PB and over
Function
code
Function
Name
LCD
Display
Range of settings Default Change
MODBUS
Address
P3.03
Multi-fu
nction
input
selection
Terminal
X3
Termin
al X3
functio
n
37 × 0403
P3.04
Multi-fu
nction
input
selection
Terminal
X4
Termin
al X4
functio
n
22: S5 Multi-step Speed
5
23: S6 Multi-step
Speed6
24: S7 Multi-step
Speed7
25: Command channel
switch to Terminal
control 2
26: SS1 Multi-step
Speed
27: SS2 Multi-step
Speed
28: SS3 Multi-step
Speed
29: Command channel
switch to Keyboard
control
30: T1 Acc/Dec time1
31: T2 Acc/Dec time1
32: T3 Acc/Dec time1
33: T4 Acc/Dec time1
34: TT1 Acc/Dec time1
35: TT2 Acc/Dec time1
36: Forced outage
normally close
37: EH0: External fault
signal normally open
38: EH1: External fault
signal normally close
39: EI0: External
interrupt signal
normally open
40: EI1: External
interrupt signal
normally close
41: Reserved
42: Start PLC operation
26 × 0404
