Alpha ALPHA6000 Series - Page 79

Chapter 4 Parameter Index
http://www.acdrive-china.com
79
Function
code
Function
Name
LCD
Display
Range of settings Default Change
MODBUS
Address
P3.13
Define
Function
s of
terminal
DO
Functio
ns of
termina
l DO
0
× 040D
P3.14
Terminal
Y1
function
definitio
n
Termin
al Y1
functio
n
0: NULL
1: RUN
2: FAR: Frequency
arriving
3: FDT: Frequency
detection threshold
4: FDTH: Frequency
upper limit arriving
5: FDTL: Frequency
lower limit arriving
6: Upper and lower
limits of Wobble
frequency
7: Zero-speed running
8: Completion of
simple PLC
operation
9: PLC cycle
completion
indication
10: Ac drive ready
(RDY)
11: Coast-to-stop
12: Auto restart
13: Timing Arriving
14: Counting value
arriving output
15: Preset operating
time arriving out
16: Torque arriving
detection threshold
17: CL: Current Limit
18: Over-voltage stall
19: Ac drive fails
20: External fault stop
(EXT)
21: Uu1: Under
voltage lock-up
22: Reserved
1
× 040E
