Alpha ALPHA6000 Series - Page 80

Chapter 4 Parameter Index
http://www.acdrive-china.com
80
Function
code
Function
Name
LCD
Display
Range of settings Default Change
MODBUS
Address
P3.15
Terminal
Y2
function
definitio
n
Termin
al Y2
functio
n
2
× 040F
P3.16
Output
functions
selection
of relay 1
(TA/TB/
TC)
Relay
output
23: OLP: Overload
signal
24: Analog signals1
abnormal
25: Analog signals2
abnormal
26: STEP:
Programming
Running steps (only
active to
DO\Y1\Y2, and
need to set P3.13,
P3.14, P3.15 the
same value as 26)
27: Fault type output
(Only active to
DO\Y1\Y2, and
need to set P3.13,
P3.14, P3.15 the
same value as 27)
28: Fixed-length
arrived, output a
high level signals
29: Standby
30: Zero-speed running
Note: Function code
P3.14 and P3.15 can’t
be set, while 26
and27’s
output functions are
reserved
19
× 0410
