Alpha ARES 150 Tec - Reversing the Connections

20
Instructions for the installer
3.7 REVERSING THE CONNECTIONS
e ARES Tec ErP boiler leaves the factory set up for hydraulic (ow
and return), gas and ue exhaust connections located on the RIGHT
side of the boiler.
Reversing FLUE GAS
To move the ue exhaust to LEFT simply switch the two sides of the
casing around.
FOR MODELS 250 - 300 - 350
To move the ue exhaust from Right (standard posi-
tion) to the rear position, you need to request the
optional ue kit consisting of the Ti shown in the
gure and a closing plate for the hole in the Rh side
of the casing.
FOR MODELS 150 - 200
it is necessary to request the ue kit comprised of a
closing plate over the hole on the Rt side of the casing. .
Reversing GAS
To move the gas connection,
switch the blind ange with
the anged stub pipe.
Reversing SYSTEM FLOW AND RETURN
To move the Flow / Return connections to the opposite side,
switch the blind ange with
the anged stub pipe.
To move the hydraulic
connections (one or both) to
the LEFT side, remove the
pre-sectioned part on the
attachments that you intend to
move to the opposite side and
close the RIGHT side of the
casing with the caps supplied
with the boiler.
