Instructions for the installer
3.14 EMERGENCY AND SAFETY
OPERATIONS
BCM
e BCM board prevents the system from shutting down if management
of the HSCP system or main boiler system are out of service (see the
BCM manual).
A YELLOW LED = ashing (communication between BMM and BCM)
ok
GREEN LED = on (Pump On)
RED LED = on (Error Code detected)
E HSCP Control panel
F Only for ARES 350 Tec Light indicating the General Limit
ermostat TLG is on
G Fuses:
1 = 6.3 A
H Main Switch
I Only for ARES 350 Tec
When TLG General Limit ermostat comes on it cuts o power to
the boiler and light F comes on. To re-arm it, take o the cap and press
Condensate level sensor position
NOTE: the devices are positioned under the casing
next to the control unit.
NOTE: the emergency function only switches the
burners on in the boiler to 100% in ow. All system
loads, including the manifold pump, must be controlled
manually.
