Inspections and maintenance
Element screws.
- Take out screws "A" from each element (with 13 mm socket key).
- Take out screws "B" (with 13 mm socket key / with 13 mm hex key)
and take out the clamping plates.
- Take out the gas pipe clamping screws (right and le side).
- Take out the four screws, followed by the gas ange, using a 10 mm
socket key.
