5.26
ENG_UD54124_2
Fusibles (XEF - Alpine)
Number Allocation
2
Passenger compartment
ECU
3
Passenger side window
control
4 Driver’s electric window
8 Service relay
9
Electric heating, cruise
control/speed limiter, Park
Assist, heated rear screen
(relay)
10 Heated rear screen
11
De-icing of electric door
mirrors
13
Right-hand main beam
headlight, left-hand dipped
beam headlight, left-hand
side light
16 Accessories socket
17 Light stalk
18 Horn
19 Brake lights
21
Radio, multimedia
accessories socket
22 Audio amplifier
23 Front windscreen wiper
24
Left-hand main beam
headlight, right-hand dipped
beam headlight, right-hand
side light
FUSES (3/4)
Number Allocation
25
Rear fog lights, registration
plate lights
26 ABS/ESC brake lights unit
27
Interior lighting, bonnet
lighting, luggage
compartment lighting,
gearbox, one-touch window
winder
28
Rain sensor, light sensor,
engine start button
29 Electric rear view mirror
30
Passenger compartment
unit, injection unit, fuel
pump, ignition coils, starter
31 Airbag unit
33
Electric power-assisted
steering
34 Radio, diagnostic socket
35
Electric windows, radio,
audio amplifier, multimedia
accessories socket, brake
lights
Number Allocation
35
(continued)
interior lighting, luggage
compartment lighting,
bonnet lighting, air
conditioning, gearbox,
engine start button, rain
sensor/light, ESP/ ABS
unit
36
Energy management
central unit, telematics
unit
37
Direction indicators,
electronic parking brake
control, cruise control
38
Opening elements -
locking / unlocking
39
Energy management
central unit
41 Alarm, lighting stalk, horn
42 Instrument panel unit
43 Gearbox
45 Heated seats
46 Interior rear view mirror
47
Passenger compartment
unit, wipe/wash stalk
