Alpine Supply Company 42 Direct Vent Gas Fireplace
VENTING REQUIREMENTS
VENT TERMINATION LOCATIONS
A=
Clearance above grade, veranda, porch, deck, or balcony (min. 12”)
B= Clearance to window or door that may be opened (12”) C=
Clearance to permanently closed window (12”)
(recommended to prevent condensation on window) D= Vertical clearance to ventilated soffit located above the terminal
within a horizontal distance of (24”) from the centerline of the terminal (min. 18”)
E= Clearance to unventilated soffit (min. 15”) F= Clearance to outside corner (19”) G= Clearance to inside corner (12”) H= Not to be installed above a meter / regulator assembly within (3’)
horizontally from the centerline of the meter.
J=
Clearance to service regulator vent outlet (min. 36”)
K=
Clearance to non-mechanical air supply inlet to building or the
combustion air inlet to any other appliance (12”)
L=
Clearance to a mechanical air supply inlet (36”)
M=
Clearance above paved sidewalk or a paved driveway located on
public property (min. 84”) N= Clearance under a veranda, porch, deck, or balcony (min. 12”) P= Clearance to obstructions in front of the termination such as bushes, fences, sheds, decks, other structures is (24”)
Note: - A vent shall not terminate directly above a sidewalk or paved driveway which is located between two single family dwellings and serves both dwellings. - Only permitted if veranda, porch, deck, or balcony is fully open on a minimum of two sides beneath the floor. - If the vent termination is accessible a certified guard should be installed. - Local codes or regulations may require different clearances.
Vertical Termination
24"
D
E
V
P
V
M
B
F
V
V
V
V
V
V
V
V
G
A
Inside
corner detail
Vertical Termination
24"
18"
H
L
N
A
J
B
B
B
B
A
K
Openable
A
Openable
B
C
Fixed
Closed
A
Air supply outletV
Vent terminal
Area where terminal is not permitted
