26-EN
Using the Front AUX Input Terminal
Connect a portable music player, etc. by simply connecting it to the
input on the front panel. An optional adapter cable is required (standard
RCA to 3.5ø mini-phono plug or 3.5ø to 3.5ø mini-phono plug).
Press VSOURCE, and select the AUXILIARY mode to
listen to the portable device.
CDE-W296BT
CDE-195BT
Note
• This function is available only when AUX SETUP is set to ON. For
details, refer to “Setting the AUX SETUP mode” on page 29.
Option Menu Setting
You can quickly adjust the setting items relevant to the current SOURCE
by using Option Menu.
1
Press and hold ENTER/OPTION for at least 2 seconds
to activate the Option menu of the current source.
Note
• The option menu varies depending on the source.
2
Turn the Rotary encoder to select the desired setting
item, and then press ENTER.
3
Turn the Rotary encoder to change the setting, and then
press ENTER.
After the setting, the display will return to the current source
automatically.
The following setting items are displayed when MENU LANG is
set to ENGLISH. For details, refer to “Setting the Menu Language”
on page 29.
Setting item:
TUNER mode:
PTY SELECT
*1
TUNER SET
*2
SOURCE VOL
*3
PTY SELECT
DISC mode:
CD SET
*4
SOURCE VOL
*3
MX SETTING
*5
CD SET
USB mode:
SOURCE VOL
*3
MX SETTING
*5
SOURCE VOL
iPod mode:
APP DIRECT
*6
IPOD SET
*7
SOURCE VOL
*3
MX SETTING
*5
APP DIRECT
AUX mode:
AUX SET
*8
SOURCE VOL
*3
MX SETTING
*5
AUX SET
BT AUDIO mode:
BT SET
*9
SOURCE VOL
*3
MX SETTING
*5
BT SET
Phone mode (Non-calling mode):
PHONE SET
*10
SOURCE VOL
*11
PHONE SET
Phone mode (Calling mode):
MIC GAIN
*12
CALL SOUND
*12
SPK SWITCH
*13
VOICE MUTE
*14
CALL WAIT
*15
END CALL
*16
SOURCE VOL
*11
MIC GAIN
*1 Refer to “PTY (Programme Type) Tuning” on page 13.
*2 The setting items are the same as TUNER setting in SETUP
mode. For details, refer to “SETUP” on page 28.
*3 You can individually emphasise or weaken the volume level
of the current source to create your own tonal preference. The
setting values in Option mode and in SETUP mode are
linked. Refer to “Setting the Source Volume Level” on page 19.
*4 PLAY MODE can be selected in this mode. For details, refer
to “Playing MP3/WMA/AAC Data (PLAY MODE)” on
page 29.
*5 Refer to “Setting the Media Xpander mode” on page 21.
*6 Refer to “Setting the iPod Control” on page 40.
*7 The setting items are the same as iPod setting in SETUP
mode. For details, refer to “iPod/iPhone Search Mode
Setting” on page 31.
*8 AUX NAME can be selected in this mode. For details, refer to
“Setting the AUX NAME mode” on page 29.
*9 FW VERSION can be selected in this mode. You can see the
current firmware version about Bluetooth by using this
setting.
*10 CALL SOUND, CALLER ID, PB UPDATE, PB ORDER,
SPEAKER SL and FW VERSION can be selected in this
mode. For details about these settings, refer to “Bluetooth
SETUP” on page 33.
*11 The Hands free phone talk level, ring tone level and
microphone gain level can be adjusted by using this setting.
The setting values in Option mode and in SETUP mode are
linked. Refer to “Adjusting the volume (SOURCE VOL)” on
page 34.
*12 Refer to “Setting the Bluetooth sound quality” on page 34.
*13 While calling, the call sound can be switched between the
unit and Smartphone by using this setting.
This operation can also be done by pressing OBAND.
Refer to “Call Switching Operation” on page 37.
Portable player, etc.
Main unit
or
Optional adapter cable (RCA pin
plugs [red, white] 3.5ø miniplugs)
or (3.5ø miniplugs).
Portable player, etc.
Main unit
or
Optional adapter cable (RCA pin
plugs [red, white] 3.5ø miniplugs)
or (3.5ø miniplugs).
To Next Page
