Alpine CDE-W296BT User Manual

51-EN
About the Rules of Bluetooth Electromagnetic
Radiation Regulation
Declaration of Conformity
 Adaptive Steering Remote G.GND
To adaptive steering remote control interface box.
For details about connections, consult your nearest Alpine dealer.
 Adaptive Steering Remote Control In 1 Lead (Brown/Yellow)
To adaptive steering remote control interface box.
For details about connections, consult your nearest Alpine dealer.
 Adaptive Steering Remote Control In 2 Lead (Brown/Orange)
To adaptive steering remote control interface box.
For details about connections, consult your nearest Alpine dealer.
 Antenna Receptacle
 Front Output RCA Connectors
RED is right and WHITE is left.
 Rear Output RCA Connectors
RED is right and WHITE is left.
 Subwoofer Output RCA Connectors
RED is right and WHITE is left.
 Steering Remote Control Interface Connector
To steering remote control interface box. For details, contact your
Alpine dealer.
 MIC Input Connector
To M icrophone.
 Fuse Holder (10A)
 Power Supply Connector
 Microphone (Included)
 Remote Turn-On Lead (Blue/White)
Connect this lead to the remote turn-on lead of your amplifier or
signal processor.
 Switched Power Lead (Ignition) (Red)
Connect this lead to an open terminal on the vehicle’s fuse box or
another unused power source which provides (+) 12V only when the
ignition is turned on or in the accessory position.
 Ground Lead (Black)
Connect this lead to a good chassis ground on the vehicle. Make sure
the connection is made to bare metal and is securely fastened using
the sheet metal screw provided.
 Power Antenna Lead (Blue)
Connect this lead to the +B terminal of your power antenna, if
applicable.
Note
• This lead should be used only for controlling the vehicle’s power
antenna. Do not use this lead to turn on an amplifier or a signal
processor, etc.
 Dimmer Lead (Orange)
This lead may be connected to the vehicle’s instrument cluster
illumination lead. This will enable the vehicle’s dimmer control to dim
the backlighting of the unit.
 Battery Lead (Yellow)
Connect this lead to the positive (+) post of the vehicle’s battery.
 ISO Power Supply Connector
 ISO Connector (Speaker Output)
 Left Rear (+) Speaker Output Lead (Green)
 Left Rear (−) Speaker Output Lead (Green/Black)
 Left Front (+) Speaker Output Lead (White)
 Left Front (−) Speaker Output Lead (White/Black)
 Right Front (−) Speaker Output Lead (Grey/Black)
 Right Front (+) Speaker Output Lead (Grey)
 Right Rear (−) Speaker Output Lead (Violet/Black)
 Right Rear (+) Speaker Output Lead (Violet)
 RCA Extension Cable (sold separately)
 Front USB Terminal
Connect this to an USB Memory or to an iPod/iPhone.
 Front AUX Input Terminal
This terminal allows for input of audio from an external device (such
as a portable player), using a commercially-available converter cable.

Alpine CDE-W296BT Specifications

General

MP3 playback	Yes
Audio formats supported	AAC, MP3, WMA
FM band range	87.5 - 108 MHz
LW band range	153 - 281 kHz
Supported radio bands	FM, LW, MW
Preset stations quantity	30
DIN size	2 DIN
Output power	200 W
RDS features	AF, CT, EON, PTY, TA, TP
Product color	Black
Disc types supported	CD, CD-R, CD-RW
Audio output channels	4.0 channels
Equalizer bands quantity	9
Maximum power per channel	50 W
Signal-to-Noise Ratio (SNR)	105 dB
Display type	LCD
On Screen Display (OSD) languages	DEU, DUT, ENG, ESP, FRE, ITA, RUS
Bluetooth version	2.1+EDR
Bluetooth profiles	A2DP, AVRCP, HFP, HSP, OPP, PBAP, SPP
Key illumination color	Multi
Operating temperature (T-T)	-10 - 60 °C

Weight and Dimensions

Weight	1850 g
Dimensions (WxDxH)	178 x 161.7 x 100 mm
