Alpine iLX-W670 - Sound Setup; Fader;Balance; Bass;Middle;Treble; EQ Setting

33-EN
Sound Setup
[Sound] is selected on the Setup menu screen.
You can set up items related to the sound quality.
<Setting item>
Fader/Balance (page 33)
Bass/Treble (page 33)
EQ Setting (page 33)
Preset EQ (page 34)
X-Over (page 35)
Speaker Level (page 36)
Time Correction (page 35)
Sub Woofer (page 35)
Defeat (page 36)
*
Touch [ ] or [ ] to show further .
Setting the Fader/Balance
A
Back
Exit[Fader/Balance]Return [SOUND].
B
Close
Close the current screen and return to the source screen
C
Fader/Balance Image area
Touch the desired point within the image area, or touch [ ],
[ ], [ ] or ].
Fader:
[15]Front to [15]Rear
Balance:
[15]Left to [15]Right
•
To reset to the initial setting (Fader: F=R, Balance: L=R), touch [ ].
Adjusting the Bass/Middle/Treble
Touch [ ] or [ ] for each item to be adjusted.
Setting item:
Bass, Middle, Treble
Setting contents:
-12 to 12 (Initial setting: 0)
•
To reset the initial setting (Bass: 0, Middle: 0, Treble: 0), touch [Flat].
•
When the Defeat setting is [On], you cannot perform the set up.
Adjusting the Graphic Equalizer Curve (EQ)
Setting item:
EQ
•
When the Defeat setting is [On], you cannot perform the set up.
1
Adjust the EQ to your preference.
Adjusting the Band
Touch [Band] to select the band to be adjusted.
Band1 Band2 ••• Band8 Band13 Band1
•
You can select a band directly by touching the screen.
Adjusting the Frequency
Touch of “Frequency” to adjust the frequency of the selected band
