62-EN
01GB05INA-W900E.fm
ALPINE INA-W900E 68-16909Z25-A (EN)
Display Setup Operation
1
Touch [SETUP] on the main source screen.
The SETUP main screen is displayed.
2
Touch [DISPLAY SETUP].
The Display Setup screen appears.
3
Touch [], [] or [] etc., of the desired item to
change its setting.
Setting items:
TILT*
1
/ VISUAL EQ / DIMMER / DIMMER LOW LEVEL /
BASE COLOR / SCREEN ALIGNMENT
*
1
For operation, refer to “Adjusting the Monitor Viewing Angle” on
page 14.
4
Touch [] to return to the previous screen.
Touch [ESC] to return to the main source screen that was
displayed before the setup operation was started.
• Immediately after changing the settings of Display Mode (While the
system is writing data automatically) do not turn the ignition key
(engine key) to OFF. Otherwise, the settings may not be changed.
The visual setting of Bright, colour, contrast, etc. can be adjusted in this
mode.
Setting item: VISUAL EQ
Further setting items:
VISUAL EQ* BRIGHT COLOR* TINT*
CONTRAST SHARP* USER MEMORY*
* The setting is unavailable in navigation mode.
Touch [] or [] etc., of the desired item to change its
setting.
• The settings are available in the visual source mode only.
• The further setting items can be changed by touching [ ]/[].
• Only one setting item can be displayed on each page, you can select
the desired brightness, picture tint, etc through the screen displayed.
Selecting the Visual EQ Mode (Factory’s setting)
You can select a mode suitable for the subject image.
Further setting item: VISUAL EQ
Setting contents: OFF (FLAT) / NIGHT M. / SOFT / SHARP /
CONTRAST / P-1 / P-2
• To return to the default video settings, set this function to OFF. Any
Visual EQ selection or changes made are reset their initial settings.
• If any adjustments are made to the existing Visual EQ selections
(NIGHT M., etc.), “CUSTOM” is displayed.
Adjusting Brightness
Further setting item: BRIGHT
Setting content: -15 ~ +15
You can adjust the brightness between Min (-15) and Max (+15).
When it reaches the minimum or maximum point, the display
shows “MIN” or “MAX” respectively.
• When any Visual EQ Preset is selected, the brightness is
automatically adjusted according to the car’s interior lighting as
long as AUTO is set in “Setting the Brightness of the Backlighting”
(page 63).
Adjusting Colour of Picture
Further setting item: COLOR
Setting content: -15 ~ +15
You can adjust the colour between Min (-15) and Max (+15).
When it reaches the minimum or maximum point, the display
shows “MIN” or “MAX” respectively.
• Colour adjustment can be made only in DVD, Video CD and AUX
modes.
Adjusting Tint of Picture
Further setting item: TINT
Setting content: G15 ~ R15
Adjust the colour from G15 to R15. “G MAX” or “R MAX” is
displayed at the maximum of each colour.
• Tint adjustment can be made only in DVD, Video CD and AUX
modes.
• When setting PAL, you can not adjust the TINT.
Adjusting Image Contrast
Further setting item: CONTRAST
Setting content: -15 to +15
Contrast adjustment range is -15 to +15. “LOW” and “HIGH”
appear as the minimum and maximum values specified.
DISPLAY Setup
The Parking Brake must be engaged to access the DISPLAY
mode screen. Attempting to access this screen while driving will
display the warning-CAN’T OPERATE WHILE DRIVING.
The following steps 1 to 4 are common operations to each
“Setting item” of DISPLAY Setup. Refer to each section for
details.
Visual EQ Setting Operation
OFF (FLAT): Initial Setting
NIGHT M.: Suitable for movies in which dark scenes
frequently appear.
SOFT: Suitable for CGs and animated films.
SHARP: Suitable for old movies where images are not
clearly shown.
CONTRAST: Suitable for recent movies.
P-1: Recalls the Visual EQ mode being stored on
preset No.P-1 from “Storing Visual EQ” (page 63).
P-2: Recalls the Visual EQ mode being saved on
preset No.P-2 from “Storing Visual EQ” (page 63).
01GB00INA-W900E.book Page 62 Monday, September 13, 2010 9:52 AM
