Before performing the following procedures, refer to “About Time
Correction” (page 77).
Setting item: T.CORR
1
Touch [] of T.CORR.
The T.Corr adjustment screen appears.
2
Adjust the distance (0.0 to 336.6 cm) of a desired
speaker by touching the respective [] or []
button.
L = (distance to farthest speaker) – (distance to other
speakers)
Refer to “Time Correction Value List” on page 77.
3
Repeat step 2 to set another speaker.
Set these values to achieve simultaneous sound
propagation to the listening position from all speakers.
You can change the unit, (cm or inch) of time correction.
Touch [ ] or [ ] of T.CORR PARAMETER to select cm or Inch.
Setting item: T.CORR PARAMETER
cm Inch
You can modify the equalizer settings to create a response curve more
appealing to your personal taste.
Setting item: G-EQ
1
Select L+R by touching [] of G-EQ.
When parametric EQ is set to L+R, this setting will be turned
off.
2
Touch [] of G-EQ after selecting L+R.
The G-EQ list screen appears.
3
Adjust the G-EQ to your preference.
Adjusting the Band
Touch [] or [] of BAND to select the band to be adjusted.
BAND-1 (63 Hz) / BAND-2 (150 Hz) / BAND-3 (400 Hz) /
BAND-4 (1 kHz) / BAND-5 (2.5 kHz) / BAND-6 (6.3 kHz) /
BAND-7 (17.5 kHz)
Adjusting the Level
Touch [] or [] of LEVEL to adjust the level of selected
band.
Adjustable output level: –6 to +6 dB
4
To adjust another band, repeat step 3, and then
adjust all bands.
• When Graphic EQ is adjusted, the adjustment for Parametric EQ
becomes ineffective.
You can modify the Equalizer settings to create a response curve more
appealing to your personal taste.
Setting item: P-EQ
1
Select L+R by touching [] of P-EQ.
When graphic EQ is set to L+R, the setting will be turned off.
2
Touch [] of P-EQ after selecting L+R.
The P-EQ list screen appears.
3
Adjust the P-EQ to your preference.
Adjusting the Band
Touch [ ] or [ ] of BAND to select the band to be
adjusted.
BAND 1 / BAND 2 / BAND 3 / BAND 4 / BAND 5
Adjusting the Frequency
Touch [] or [] of FREQ. to adjust the frequency of the
selected band.
Adjustable frequency bands:
20 Hz to 20 kHz (in 1/3 octave steps)
Band-1: 20 Hz~80 Hz (63 Hz)
Band-2: 50 Hz~200 Hz (150 Hz)
Band-3: 125 Hz~3.2 kHz (400 Hz)
Band-4: 315 Hz~8 kHz (1 kHz)
Band-5: 800 Hz~20 kHz (2.5 kHz)
Adjusting the Level
Touch [] or [] of LEVEL to adjust the level of selected
band.
Adjustable level: –6 to +6 dB
Setting the Bandwidth
Touch [] or [] of Q to select the bandwidth.
Adjustable bandwidth: 1, 1.5, 3
4
To adjust another band, repeat step 3 and adjust all
bands.
• The frequencies of adjacent bands cannot be adjusted within 4 steps.
• While adjusting the Parametric EQ, you should consider the
frequency response of the connected speakers.
• When the Parametric EQ is adjusted, the adjustment for Graphic EQ
becomes ineffective.
10 typical equalizer settings and 6 user’s preset setting are preset at the
factory for a variety of musical source material.
Setting item: F-EQ
1
Touch [] of F-EQ.
The F-EQ setup screen appears.
2
Touch [] or [] of the desired type to set to ON.
Flat / Pops / Rock / News / Jazz&Blues / Electrical Dance /
Hip Hop&Rap / Easy Listening / Country / Classical / User1 /
User2 / User3 / User4 / User5 / User6
• Only one type can be set to ON.
• By selecting User’s 1 to 6, you can recall the stored preset number in
“Adjusting the Graphic Equalizer Curve (G-EQ)” (page 75) or
“Adjusting the Parametric Equalizer Curve (P-EQ)” (page 75) .
Adjusting the Time Correction (T.Corr)
Setting the Time Correction Unit (T.Corr
Parameter)
cm: The unit of time correction is cm.
Inch: The unit of time correction is Inch.
Adjusting the Graphic Equalizer Curve
(G-EQ)
Adjusting the Parametric Equalizer Curve
(P-EQ)
Equalizer Presets (F-EQ)
01GB00INA-W900E.book Page 75 Monday, September 13, 2010 9:52 AM
