Adjusting Picture Quality
Further setting item: SHARP
Setting content: -15 to +15
Picture quality adjustment range is -15 to +15. “SOFT” and
“HARD” appear as the minimum and maximum values specified.
• Picture quality adjustment can be made only in DVD, Video CD and
AUX modes.
Storing Visual EQ
You can store the settings made for “Adjusting Image Brightness, Tint,
Colour, Picture Quality and Contrast.”
Further setting item: USER MEMORY
Setting contents: P-1 / P-2
1 After completing “Adjusting Brightness, Tint, Colour,
Picture Quality, and Contrast” (pages 62 and 63), touch
[] or [] of USER MEMORY and then select preset No.
“P-1” or “P-2” to which the settings are to be stored.
2 After selecting a preset No., touch [MEMORY].
The adjusted Visual EQ mode is stored by the above
operations.
• You can recall the Visual EQ mode stored here from P-1 or P-2 of
“Selecting the Visual EQ Mode (Factory’s setting)” (page 62).
Backlighting is provided by a fluorescent light built into the liquid
crystal panel. The illumination control adjusts the brightness of the
backlighting based on the car ambient lighting for easier viewing.
Setting item: DIMMER
Setting contents: OFF / ON / AUTO
• When ON or AUTO is set, the setting is also applied for the button
lighting in “Adjusting the Dimmer of Button Lighting at Night”
(page 64).
You can adjust the brightness of the backlight (LOW). This function
could be used, for instance, to change the screen brightness while
traveling at night.
Setting item: DIMMER LOW LEVEL
Setting content: -15 to +15
You can adjust the level between Min (-15) and Max (+15). When
it reaches the minimum or maximum point, the display shows
“MIN” or “MAX” respectively.
You can choose from 4 different display colours for the font back
(source title, shortcut display, etc.).
Setting item: BASE COLOR
Setting contents: BLUE / RED / GREEN / AMBER
Adjustment becomes necessary when the display position on the LCD
and the touch position on the touch panel do not match.
Setting item: SCREEN ALIGNMENT
Setting contents: / RESET
1 Touch [] of SCREEN ALIGNMENT.
The adjustment screen appears.
2 Accurately touch the mark provided in the lower left
corner of the screen.
The screen changes to the adjustment screen.
3 Accurately touch the mark provided in the upper right
corner of the screen.
This completes adjustment, and returns to the Display
setup mode screen.
• If you have touched a location other than the mark, touch
[RESET] to restore the adjustment screen to the initial setting.
• If you touch [] on the adjustment screen, no adjustment is done
and the Display setup screen is restored.
Setting the Brightness of the Backlighting
OFF: Deactivate Auto Dimmer mode to keep the background
illumination of the monitor bright.
ON: Keep the background illumination of the monitor dark.
AUTO: Adjust the brightness of the background illumination of
the monitor automatically to the brightness of the car
interior.
Adjusting the Minimum Level of Backlight
Switching the Font Back Display Colour
Adjusting the Touch Panel
01GB00INA-W900E.book Page 63 Monday, September 13, 2010 9:52 AM
