Aircraft Systems
POWER PLANT
AL250 Flight Manual
MEP
CARB HEAT
The Carb Heat knobs are located to the right of the pilot’s wheel.
Figure 6.10: Carb Heat Knobs
NOTE
On the BPG9 flight model, the induction air temp er-
ature limitation cannot be exceeded with preheat.
NOTE
Only the left Carb Heat k nob is functional on single
engine flight models.
Rev. 1.8 © 2021 ALSIM - All Rights Reserved 6-13
