Alsim al250 - Vacuum Gauge

Aircraft Systems
FLIGHT INSTRUMENTS
AL250 Flight Manual
MEP
6-5-6 VACUUM GAUGE
The vacuum gauge is located on the central panel. It shows the pressure in the gyro
suction system in units of in.Hg. with numerals at 4, 5, 6 in.Hg.
Figure 6.30: Vacuum Gauge
Rev. 1.8 © 2021 ALSIM - All Rights Reserved 6-28
