H38x/EN GL/D11 Global Documentation
Page 22/53
DS Agile H38x
4. TECHNICAL DATA
4.1 DS Agile H38x Range
Ports
10/100Base-Tx
Copper
100 Base-Fx
Multimode (PRP)
100 Base-Fx Single
Mode (PRP)
DS Agile H382 3 2 (LC) -
DS Agile H384 3 - 2 (LC)
4.2 Conformity
(As per Article 10 of EC Directive 2006/95/EC).
The products designated “DS Agile H382”, and “DS Agile H384” have been designed and
manufactured in compliance with standard EN 60950-1:2006 and are compliant with
European Commission Low Voltage Directive 2006/95/EC.
4.3 Ethernet Port Characteristics
4.3.1 10/100Base-Tx Port
Connector type Shielded RJ45 jack
Twisted pair cable Cat 5
Max. cable length with Cat 5 100 m
TABLE 1: 10/100BASETX PORT CHARACTERISTICS
4.3.2 100Base=Fx Multimode Port
Fibre port connector LC
Optimal fibre cable 62.5/125 µm or 50/125 µm
Centre wavelength 1310 nm
TX output power -20 dBm
RX input sensitivity -31 dBm
Maximum distance 2000 m (Approximate. Refer to the Application section for
guidance)
TABLE 2: 10/100BASEFX MULTIMODE PORT CHARACTERISTICS
4.3.3 100Base-Fx Single Mode Port
Fibre port connector LC
Optimal fibre cable 9/125 or 10/125 µm
Centre wavelength 1310 nm
TX output power -15 dBm
RX input sensitivity -31 dBm
Maximum distance 15 km (Approximate. Refer to the Application section for
guidance)
TABLE 3: 10/100BASEFX SINGLE MODE PORT CHARACTERISTICS
