Global Documentation H38x/EN GL/D11
DS Agile H38x
Page 25/53
CM Earth connector NA
CM Copper Ethernet port 2kV
CM IRIG-B connector 5kV
DM Housing NA
DM Power supply 3kV
DM Alarm contact 3kV
DM Earth connector NA
DM Copper Ethernet port NA
DM IRIG-B connector 3kV
4.6.1.4
Earthing continuity
Standard: IEC 61131-2
Application mode Group under test Test level
NA Housing Resistance
< 0,1Ω ; I = 30A ; 2min
NA Power supply NA
NA Alarm contact NA
NA Earth connector Resistance
< 0,1Ω ; I = 30A ; 2min
NA Copper Ethernet port NA
NA IRIG-B connector NA
4.6.2 Electromagnetic compatibility
4.6.2.1
Electrostatic Discharge
Standard: IEEE 1613 / ANSI/IEEE C37.90.3
Application mode Group under test Test level
NA Housing Class 4 : ± 8kV contact
discharge ; ± 15kV air
discharge
NA Power supply NA
NA Alarm contact NA
NA Earth connector NA
NA Copper Ethernet port NA
NA IRIG-B connector NA
4.6.2.2
Radiated immunity
Standard: IEC 61850-3
/ EN 61000-4-3
Application mode Group under test Test level
NA Housing Radiated immunity, Class 4 :
- 30V/m @ 1kHz 80%am ;
80MHz to 1GHz
- Radiated immunity from
digital radio telephones, Class
4 : 30V/m @ 1kHz 80% am ;
To Next Page
