Global Documentation H38x/EN GL/D11
DS Agile H38x
Page 33/53
Application mode Group under test Test level
Energised Housing 70 kPa ≤ air pressure ≤ 106 kPa
4.6.6 Mechanical
4.6.6.1
Stationnary vibration sinusoidal immunity
Standard: IEC 61850-3/ IEEE 1613
/ IEC 60870-2-2 / IEC 60068-2-6
Application mode Group under test Test level
Energised Housing Class Bm : 3mm ; 2 to 9Hz & 1,0g ; 9 to 200Hz &
1,5g ; 200 to 500Hz
4.6.6.2
Free fall immunity
Standard: IEC 61850-3/ IEEE 1613/ IEC 60870-2-2 / IEC 60068-2-31
Application mode Group under test Test level
Not energised Housing 2 falls of 50mm on each 4 faces
4.6.6.3
Vibration response immunity
Standard: IEC 60255-21-1
Application mode Group under test Test level
Energised Housing Class 2 : 1g ; 10 to 150Hz ; 1sweep cycles/ axis
4.6.6.4
Vibration endurance immunity
Standard: IEC 60255-21-1
Application mode Group under test Test level
Not energised Housing Class 2 : 2g ; 10 to 150Hz ; 20 sweep cycles/
axis
4.6.6.5
Shock immunity
Standard: IEC 61850-3
/ IEC 60870-2-2 / IEC 60255-21-2
Application mode Group under test Test level
Energised Housing Class 2 : 10g ; 11ms ; 6 pulses/ axis
Not energised Housing Class 1 : 15g ; 11ms ; 6 pulses/ axis
4.6.6.6
Bump immunity
Standard: IEC 60255-21-2
Application mode Group under test Test level
Not energised Housing Class 1 : 10g ; 16ms ; 2000 bumps/axis
4.6.6.7
Seismic immunity
Standard: IEC 61850-3/ IEC 60870-2-2 / IEC 60255-21-3
