Typing in the “getSwitchATU” command will return the switch Address Translation (ATU)
table:
The Address Translation Unit (ATU) performs MAC address searching, learning, and ageing
functions for all ports of the switch. By default, the ATU table allows a total of 1024 entries
and an ageing time is 300 seconds for each entry. An example of using the “getSwitchATU”
command is given in the figure below.
~ # getSwitchATU
#1:00:02:84:03:ff:02(2)
#2:00:10:a4:df:87:07(4)
#3:80:b3:2a:ff:e0:96(4)
#4:80:b3:2a:ff:e0:97(5)
MAC Address Switch port number
Typing “pn” returns the proxy node table. The proxy node table keeps track of peer PRP
nodes. The key attribute of the node table is the MAC address of the source node as
received in the PRP supervision frame sent by a PRP node. By default the proxy node entry
is cleared after 60s although this time can be changed by changing the value in the
PNT_AGT register.
An example of extracting a proxy node table is given in the figure below:
~ # pn
00:16:d3:b7:51:46
00:50:da:e4:e6:e0
2 entries in proxy node table
8.6 Help command
During a session, if you enter “h” at the command line the interface will display all
parameters that are used to configure and manage the switch. This includes:
− Configuration commands
− Management commands
− Informative commands
− PRP registers
− Information on the PRP and Ethernet switch ports
