H38x/EN GL/D11 Global Documentation
Page 2/53
DS Agile H38x
3.5.1 LED Indications 19
3.5.2 Alarm contacts 21
3.5.3 TELNET Port 21
4. TECHNICAL DATA 22
4.1 DS Agile H38x Range 22
4.2 Conformity 22
4.3 Ethernet Port Characteristics 22
4.3.1 10/100Base-Tx Port 22
4.3.2 100Base=Fx Multimode Port 22
4.3.3 100Base-Fx Single Mode Port 22
4.4 General Characteristics 23
4.4.1 Mechanical 23
4.4.2 Auxiliary Power Supply 23
4.4.3 Auxiliary Fault Relays (Power Alarm and Optical Port Alarm) 23
4.5 Ethernet Management 23
4.6 Environmental Characteristics 23
4.6.1 Dielectric, impulse and insulation 23
4.6.2 Electromagnetic compatibility 25
4.6.3 DC auxiliary power supply 30
4.6.4 AC auxiliary power supply 31
4.6.5 Atmospheric 32
4.6.6 Mechanical 33
4.6.7 Low Voltage Directive 34
4.6.8 Degrees of protection provided by enclosures 34
5. INSTALLATION 35
6. MAKING CONNECTIONS TO THIS PRODUCT 36
6.1 Connection of the protective conductor (earth) 36
6.2 Cable fitting 37
6.3 Power supply wiring 37
6.4 Alarm contacts 39
6.5 Ethernet Connection 39
6.5.1 Ethernet cable type 39
6.5.2 Parallel Redundancy Protocol (PRP) fibre-optic Ethernet port 39
7. MAINTENANCE 40
7.1 Scope 40
7.2 Pre-Maintenance Requirements 40
7.3 Repair 40
7.3.1 Replacing the DS Agile H38x 40
