Installation
Mounting the frame
P31--1001 EN/03
6/8
01--2011
© ALSTOM 2010. All rights reserved. Information contained in this document is indicative only. No representation or warranty is given or should be
relied on that it is complete or correct or will apply to any particular project. This will depend on the technical and commercial circumstances. It is
provided without liability and is subject to change without notice. Reproduction, use or disclosure to third parties, without express written authority, is
strictly prohibited.
GRID
Mounting the frame legs, continued
Instructions
The table below shows the steps for fitting the frame legs :
Step Action
6
Mount the two short reinforcements (4), making sure to respect
the direction of installation.
Do not block the fasteners (5).
4
x4
5
H M16--45
4
1
To Next Page
