Installation
Mounting the frame
P31--1001 EN/03
7/8
01--2011
© ALSTOM 2010. All rights reserved. Information contained in this document is indicative only. No representation or warranty is given or should be
relied on that it is complete or correct or will apply to any particular project. This will depend on the technical and commercial circumstances. It is
provided without liability and is subject to change without notice. Reproduction, use or disclosure to third parties, without express written authority, is
strictly prohibited.
GRID
Mounting the two cabinet supports, optional
Reminder
The cabinet supports can by provided by the client or by ALSTOM Grid.
Introduction
If the support frames have been provided by ALSTOM Grid, make sure all
components required for assembly are present.
Necessary
components
List of ALSTOM Grid items necessary for the operation :
Mark Illustration Description Quantity
(6)
Left cabinet support
(Optional)
1
(7)
Right cabinet support
(Optional)
1
(8)
Fittings
H M16-45
4
Continued on next page.
To Next Page
