Altec DRM 12 - ASSEMBLY, HAND CRANK CHUTE ROTATION, DRUM CHIPPER

ASSEMBLY, HAND CRANK CHUTE ROTATION, DRUM CHIPPER
ITEM NO. QTY PART NUMBER DESCRIPTION
970403928 ASSEMBLY
,
HAND CRANK CHUTE ROTATION
,
DRUM CHIPPER
1 1 970468547 UPPER DRUM HOUSING
,
WELDMENT
,
UNIVERSAL FEED
,
CHUTE ROTATION
,
DRUM CHIPPER
2 1 970468972 WELDMENT
,
CHUTE ROTATION LOCK
,
DRUM CHIPPER
3 1 970227270 CHAIN ASSEMBLY
,
5.29 FT
,
WITH CONNECTOR LINK
,
HAND CRANK CHUTE ROTATION
4 1 970156427 HAND CRANK
,
ROD
,
FORMED
,
NO 606 WOODRUFF KEY
5 1 970403933 WELDMENT
,
CHAIN TENSIONER
,
CHUTE ROTATION
,
DRUM CHIPPER
6 1 970214464 PIN
,
STEEL
,
COILED
,
1.25 IN L
,
.250 IN DIA
,
STANDARD DUTY PLAIN OILED
,
7 1 970472314 COVER
,
WELDMENT
,
CHUTE ROTATION
,
CHAIN GUARD
8 1 970156368 SPROCKET
,
ROLLER CHAIN
,
.50 IN PITCH
,
NO 40
,
9 TEETH
,
.63 BORE WITH KEYWAY
9 1 970156419 WOODRUFF KEY #606
10 2 970403646 SPACER
,
CHUTE ROTATION
,
12.5 IN OD 10.04 ID
,
DRUM CHIPPER
11 1 970403645 SPROCKET
,
ROLLER CHAIN
,
.50 IN PITCH
,
NO 40
,
96 TEETH
,
DRUM CHIPPER
12 2 970156828 BEARING
,
FLANGED
,
.63 IN BORE
,
.75 IN OD
,
.50 IN L
,
IGLIDE R-PLAIN
13 1 970403929 CHAIN DRIVE CHUTE
,
ASSEMBLY
,
HEIGHT ADJUSTABLE
,
DRUM CHIPPER
14 5 020401606 WASHER
,
STEEL
,
FLAT TYPE A NARROW
,
.63 IN DIA
,
PLATED PER ALTEC PLATED & 19
,
15 8 020031210 CAPSCREW
,
STEEL
,
HEX HEAD
,
.38-16 UNC
,
2.00 IN L
,
GR 5
,
PLATED
,
16 20 020401202 WASHER
,
STEEL
,
SAE FLAT TYPE A NARROW
,
.38 IN DIA
,
PLATED 18
,
17 8 020391211 NUT
,
STEEL
,
HEX
,
OVALATED
,
.38-16 UNC
,
GR 8
,
18 2 020041408 CAPSCREW
,
STEEL
,
HEX HEAD
,
.50-13 UNC
,
1.50 IN L
,
GR 8
,
PLAIN FINISH
,
O/R/B 879060135
O
19 4 020401404 WASHER
,
STEEL
,
FLAT TYPE A NARROW
,
.50 IN DIA
,
PLATED 18
,
20 2 020391404 NUT
,
HEX
,
SELF-LOCKING
,
STEEL
,
OVALATED
,
.50-13 UNC
,
GR C
,
PLATED
,
21 2 970403647 KIDNEY PLATE
,
CHUTE ROTATION
,
DRUM CHIPPER
22 1 020031213 CAPSCREW
,
STEEL
,
HEX HEAD
,
.38-16 UNC
,
2.75 IN L
,
GR 5
,
PLATED
,
23 1 020301201 NUT
,
STEEL
,
HEX
,
.38-16 UNC
,
GR 5
,
PLATED 18
24 4 020031206 CAPSCREW
,
STEEL
,
HEX HEAD
,
.38-16 UNC
,
1.00 IN L
,
GR 5
,
PLATED
,
25 4 020031106 CAPSCREW
,
STEEL
,
HEX HEAD
,
.31-18 UNC
,
1.00 IN L
,
GR 5
,
PLATED
,
YELLOW ZINC
26 8 020401102 WASHER
,
STEEL
,
FLAT TYPE A NARROW
,
.31 IN DIA
,
PLATED 18
27 4 020391105 NUT
,
STEEL
,
TOP LOCK
,
.31-18 UNC
,
GR C
,
PLATED 18
,
28 2 040050021 GREASE FITTING
,
STRAIGHT ZERK
,
.25-28 SELF TAPPING
,
970485929-A
4A .
[PAGE 3 OF 3]
08-13
.
