FL_ADDR[8] PIN_R14 FLASH Address[8]
FL_ADDR[9] PIN_Y13 FLASH Address[9]
FL_ADDR[10] PIN_R12 FLASH Address[10]
FL_ADDR[11] PIN_T12 FLASH Address[11]
FL_ADDR[12] PIN_AB14 FLASH Address[12]
FL_ADDR[13] PIN_AA13 FLASH Address[13]
FL_ADDR[14] PIN_AB13 FLASH Address[14]
FL_ADDR[15] PIN_AA12 FLASH Address[15]
FL_ADDR[16] PIN_AB12 FLASH Address[16]
FL_ADDR[17] PIN_AA20 FLASH Address[17]
FL_ADDR[18] PIN_U14 FLASH Address[18]
FL_ADDR[19] PIN_V14 FLASH Address[19]
FL_ADDR[20] PIN_U13 FLASH Address[20]
FL_ADDR[21] PIN_R13 FLASH Address[21]
FL_DQ[0] PIN_AB16 FLASH Data[0]
FL_DQ[1] PIN_AA16 FLASH Data[1]
FL_DQ[2] PIN_AB17 FLASH Data[2]
FL_DQ[3] PIN_AA17 FLASH Data[3]
FL_DQ[4] PIN_AB18 FLASH Data[4]
FL_DQ[5] PIN_AA18 FLASH Data[5]
FL_DQ[6] PIN_AB19 FLASH Data[6]
FL_DQ[7] PIN_AA19 FLASH Data[7]
FL_OE_N PIN_AA15 FLASH Output Enable
FL_RST_N PIN_W14 FLASH Reset
FL_WE_N PIN_Y14 FLASH Write Enable
Table 4.18. Flash pin assignments.
