Chapter 2: Board Components 2–9
Connectors
September 2015 Altera Corporation MAX V CPLD Development Board Reference Manual
Table 2–15 lists the GPIO header B schematic signal names and their corresponding
MAX V CPLD device pin numbers.
J6.31 GPIO connector A pin AGPIO_27
3.3-V
E3
J6.32 GPIO connector A pin
AGPIO_28 F1
J6.33 GPIO connector A pin
AGPIO_29 E1
J6.34 GPIO connector A pin
AGPIO_30 E2
J6.35 GPIO connector A pin
AGPIO_31 D2
J6.36 GPIO connector A pin
AGPIO_32 D3
J6.37 GPIO connector A pin
AGPIO_33 C3
J6.38 GPIO connector A pin
AGPIO_34 D1
J6.39 GPIO connector A pin
AGPIO_35 E4
J6.40 GPIO connector A pin
AGPIO_36 C2
Table 2–8. GPIO Header A Schematic Signal Names and Functions (Part 2 of 2)
Board Reference Description
Schematic Signal
Name
I/O Standard
MAX V CPLD Device
Pin Number
Table 2–9. GPIO Header B Schematic Signal Names and Functions (Part 1 of 2)
Board Reference Description
Schematic Signal
Name
I/O Standard
MAX V CPLD Device
Pin Number
J7.1 GPIO connector B pin
BGPIO_P_1_R
Variable VCCIO
voltage
(1.2-V to 3.3-V)
D15
J7.2 GPIO connector B pin
BGPIO_P_2_R D16
J7.3 GPIO connector B pin
BGPIO_N_1_R C14
J7.4 GPIO connector B pin
BGPIO_N_2_R C15
J7.5 GPIO connector B pin
BGPIO_P_3_R E15
J7.6 GPIO connector B pin
BGPIO_7 B14
J7.7 GPIO connector B pin
BGPIO_N_3_R D13
J7.8 GPIO connector B pin
BGPIO_8 C12
J7.9 GPIO connector B pin
BGPIO_9 E16
J7.10 GPIO connector B pin
BGPIO_10 E14
J7.11 Power
5VIN_CONN —
J7.12 Ground
GND —
J7.13 GPIO connector B pin
BGPIO_11 F13
J7.14 GPIO connector B pin
BGPIO_12 F16
J7.15 GPIO connector B pin
BGPIO_13 F15
J7.16 GPIO connector B pin
BGPIO_14 F14
J7.17 GPIO connector B pin
BGPIO_15 G16
J7.18 GPIO connector B pin
BGPIO_16 G15
J7.19 GPIO connector B pin
BGPIO_17 G14
J7.20 GPIO connector B pin
BGPIO_18 H16
J7.21 GPIO connector B pin
BGPIO_19 H15
J7.22 GPIO connector B pin
BGPIO_20 H14
J7.23 GPIO connector B pin
BGPIO_21 J16
