2. Board Components
Introduction
This chapter introduces the major components on the MAX V CPLD development
board. Figure 2–1 illustrates major component locations and Table 2–1 provides a brief
description of all component features of the board.
1 A complete set of schematics, a physical layout database, and GERBER files for the
development board reside in the MAX V CPLD development kit documents directory.
f For information about powering up the board and installing the demonstration
software, refer to the MAX V CPLD Development Kit User Guide.
This chapter consists of the following sections:
■ “Board Overview”
■ “Featured Device: MAX V CPLD” on page 2–3
■ “Configuration, Status, and Setup Elements” on page 2–5
■ “Clock Circuitry” on page 2–7
■ “Connectors” on page 2–8
■ “General User Input/Output” on page 2–13
■ “Off-Chip EEPROM” on page 2–14
■ “Power Supply” on page 2–16
■ “Statement of China-RoHS Compliance” on page 2–16
