GPIO Headers
There are two general-purpose 2×20-pin 0.1-inch expansion headers to allow the
addition of daughtercards for supplementary board features and functions.
Table 2–15 lists the GPIO header A schematic signal names and their corresponding
MAX V CPLD device pin numbers.
Table 2–8. GPIO Header A Schematic Signal Names and Functions (Part 1 of 2)
Board Reference Description
Schematic Signal
Name
I/O Standard
MAX V CPLD Device
Pin Number
J6.1 GPIO connector A pin
AGPIO_1
3.3-V
P2
J6.2 GPIO connector A pin
AGPIO_2 M4
J6.3 GPIO connector A pin
AGPIO_3 L4
J6.4 GPIO connector A pin
AGPIO_4 N3
J6.5 GPIO connector A pin
AGPIO_5 N2
J6.6 GPIO connector A pin
AGPIO_6 N1
J6.7 GPIO connector A pin
AGPIO_7 M3
J6.8 GPIO connector A pin
AGPIO_8 M2
J6.9 GPIO connector A pin
AGPIO_9 M1
J6.10 GPIO connector A pin
AGPIO_10 L3
J6.11 Power
5VIN_CONN 5-V —
J6.12 Ground
GND ——
J6.13 GPIO connector A pin
AGPIO_11
3.3-V
L1
J6.14 GPIO connector A pin
AGPIO_12 L2
J6.15 GPIO connector A pin
AGPIO_13 K2
J6.16 GPIO connector A pin
AGPIO_14 K3
J6.17 GPIO connector A pin
AGPIO_15 J3
J6.18 GPIO connector A pin
AGPIO_16 K1
J6.19 GPIO connector A pin
AGPIO_17 J1
J6.20 GPIO connector A pin
AGPIO_18 J2
J6.21 GPIO connector A pin
AGPIO_19 H2
J6.22 GPIO connector A pin
AGPIO_20 H3
J6.23 GPIO connector A pin
AGPIO_21 G3
J6.24 GPIO connector A pin
AGPIO_22 H1
J6.25 GPIO connector A pin
AGPIO_23 G1
J6.26 GPIO connector A pin
AGPIO_24 G2
J6.27 GPIO connector A pin
AGPIO_25 F2
J6.28 GPIO connector A pin
AGPIO_26 F3
J6.29 Power
3.3VIN_CONN —
J6.30 Ground
GND ——
