malletKAT Quick Start Guide
SETTING UP YOUR EXPANDERS
If you purchased extra octaves or expanders for your malletKAT, you will need to connect
them to the main unit. We have included a video clip that will show you how to connect the
expander to the malletKAT, but below is an explanation on how to set it up.
Your Expander comes with:
(1) piece of felt with adhesive, (2) aluminum strapping bars, (1) 7 pin Expander Cable
You will need a Phillips screwdriver.
To attach your Expander to the malletKAT PRO or malletKAT EXPRESS, turn the unit off and
unplug all cords. Turn the malletKAT upside down on a flat surface. Position the Expander
upside down next to the LOWEST octave of the malletKAT.
Take the piece of felt and line it up to the side of the Expander that will be attached to
your Pro/Express. Remove the release paper on the felt and adhere it to the side of the
Expander. Set the Expander back down lining it up with the malletKAT so that the felt is
touching it.
Remove the last four screws on the malletKAT furthest from the display, two screws from
the top row and two from the bottom row.
Remove the adjacent four screws on the Expander Unit as well, two from the top row and
two from the bottom row. (These are 6-32 X 1/2” pan head phillips screws).
Position the aluminum strapping bars with the oblong hole lining up on the malletKAT
and the last two holes lining up on the Expander. Replace the screws you just removed,
attaching the strapping bars to the malletKAT and the Expander.
Turn the malletKAT back over. Plug the special Expander Cable from the malletKAT to the
Expander. Use Output number ONE on the malletKAT for a single expander, and Output
number TWO for the second expander furthest from the display.
ALWAYS plug in the Expander cable BEFORE turning on the malletKAT.
