ALTIBOX TV - Wireless TV

Home hub
UTP cat.
5 cable
UTP cat.
5 cable
Power cable
Power cable
Type of cable:
Wireless TV
Type of cable:
Wireless unit
marked ’base’
Wireless unit
(unmarked)
BASE
BASE
set-top box
BASE
1. Connect the unit
marked ’BASE’ to the
power and the network
cable.to the TV socket
on the home hub.
2. Connect the other
(unmarked) unit
(receiver) to the power.
Then connect the
network cable to the
set-top box.
3. Wait 60 seconds, then the system will be ready for use.
