22 EAV64334 06/2017
Electrical Data
Logic Type
Safety function must only be used in Source mode: current flows to input.
Cabling Label
Input Signal Safety Function
Input Signals Safety Function Units Value for STO
Logic 0 (Ulow) Vdc < 5 or open
Logic 1 (Uhigh) Vdc > 11
Current (at 19 Vdc) mA 11
Delay between STOA
and STOB s< 1
Response time of safety function ms < 10
