CLEANING & MAINTENANCE
37
GREASE COLLECTION HOOK-UP
( I F E Q U I P P E D W I T H T H I S F E A T U R E )
• Grease Collection Hose Assembly is
attached to the oven in the back.
• Place Grease Collection Containers
Collection Cart. Roll into place next to
the oven.
• Remove cap from container. Pull out
the Grease Collection Hose Assembly
from the back of the unit.
• Screw on to collection container until
snug.
• Turn ball valve handle to the ON
position.
• Automatic Grease Collection System
is electronically activated during
the chicken cooking process [
]. It is designed to save labor
and provide greater employee safety
by eliminating the need to handle hot
grease in shallow pans.
On/O
Ball Valve
Grease Collection Hose
5014542
22-3/16" (563mm)
3-3/8" (86mm)
20-1/4" (514mm)
37" (940mm)
33-1/4" (845mm)
28-1/2" (724mm)
10-1/2" (267mm)
11-3/16" (284mm)
Screw on
attachment
Optional
Mobile
Grease
Collection
Cart
Grease Collection Container
To Next Page
