(6.1) Technical Specifications
Frequency Response All inputs: 20 Hz – 22 kHz (±1 dB)
THD+N (Total Harmonic Distortion) All inputs: < 0.05% (@ 4 dBu, 1 kHz)
Gain Range Mic inputs (Channels 1-4): 0 – +48 dB
Line inputs (Channels 1-4): -15 – +33 dB
Line inputs (Channels 5-6): -20 – +20 dB
All inputs: +22 dBu max
Max Voltage Gain 68 dB (Mic Input to Main, 2TK, EFX, Control Room, Headphone
Outputs)
40 dB Line Input to Main, 2TK, EFX, Control Room, Headphone
Outputs
58 dB Mic Input to MON Output
30 dB (Line Input to MON Output)
10 dB (RETURN Inputs to MON Output)
20 dB (2TK/USB/EFX RETURN/Bluetooth to Main, 2TK, Control
Room, Headphone Outputs)
SNR (Signal-to-Noise ratio) All inputs: > 110 dBu
Phantom Power +45 ~ +49V with switch control
Impedance Mic inputs: 3.9 kΩ
All other inputs: > 10 kΩ
Aux outputs: 1 kΩ
2TK outputs: 1 kΩ
All outputs: 120 Ω
Equalization High: ±15 dB @ 12 kHz
Low: ±15 dB @ 80 Hz
Bluetooth Profile: A2DP
Module: Bluetooth 5.0
Operating Frequency: 2402 MHz – 2480 MHz
Range: 100 ft. / 30.5 m
USB Audio Interface Version: 2.0
Resolution: 16-bit
DAC Sampling: 32, 44.1, 48 kHz
ADC Sampling: 8, 11.025, 16, 22.05, 32, 44.1, 48 kHz
Connectors (6) 1/4” (6.35 mm) TRS outputs
(6) 1/4” (6.35 mm) TRS stereo L/R inputs
(4) 1/4" (6.35 mm) TRS headphone outputs
(4) 1/4" (6.35 mm) TRS mono inputs
(1) Standard RCA L/R input
(1) Standard RCA L/R output
(4) XLR inputs
(1) USB type-B input
(1) DC power input
