Alto TrueMix 800FX User Manual

5
(2.1) Connection Diagram
Items not listed under (1.1) Introduction > Box Contents are sold separately.
See the connector examples below for using XLR or 1/4” (6.35 mm) wiring as
balanced or unbalanced. This can be of help if you make your own cables.
(2.1.1) Top Panel
Example 1 – Live Sound:
Stage Monitors
House Loudspeakers
Headphones
External Effects Unit
Smartphone
Electric Guitar
Microphone
Ke
y
board
CD
Player
Tip
Sleeve
Pin 2
Pin 3
Pin 1,
linked to Pin 3
Tip
Sleeve
Ring
Pin 1
Pin 3
Tip
Sleeve
Ring
Pin 2
(Ground)
(Ground)
(Ground)
(Ground)
(Ground)
TS
TRS TRS
XLR
XLR
(2.0) SETUP
