15
8.0 INDIVIDUAL CYLINDER OFFSET MODES
8.1 Two additional functions with regard to individual cylinder timing offsets are
provided. These functions can be accessed from the individual timing mode
menu which can be entered as described below.
FROM PRESS
TIMING
THEN AT PRESS
THEN AT PRESS
8.2 The first function is used to save the current (temporary) individual offsets to
EEPROM memory. When this is done, the ignition will load these offset settings
every time the engine starts or reset is pressed. Reference SECTION 7.0 to adjust
individual (temporary) offsets.
AT THE
FIRST
OPTION
SCREEN
PRESS TO PRESS PRESS TO
SAVE FOR NEXT EXIT
OFFSETS OPTION
ENTER
NEXT
ESC
To Next Page
