15.0 CPU-95EVS MODBUS REGISTER LIST
The CPU-95EVS is compliant with the Modicon Modbus RTU standard. The
CPU-95EVS Terminal program CD contains a PC-based Modbus-compatible
monitoring program. Maximum number of registers that can be read at one
time is limited to 32. Maximum number of booleans that can be read at one
time is limited to 256. The default configuration is 19200 baud, 8 Data
bits, No Parity, 1 Stop bit (19200 8N1). The MODBUS address list is on the
following pages.
The 10xxx registers are read-only binary and support Modbus standard
function 1. These registers are read in multiples of 8 (1 byte) addressed at
each 8 bit boundary (10001-10008, etc.). A single Boolean read from registers
10001 to 10064 can be made which will return all 64 values as a group of 8
bytes. These registers also support an Altronic custom function 101 which will
return a descriptive label for each specific register. The custom label function
can be used to reduce the need for the Modbus master to maintain a current
listing of all of the register labels for each unit.
Enhanced Display Modbus Register 10000
Register Label 0 1 Notes
10001 IGN SHUTDOWN FLAG No Yes
10002 IGN WARNING FLAG No Yes
10003 IGN FAULT FLAG No Yes
10004 IGN FIRED FLAG No Yes
10005 IGN ALARM OUTPUT ACTIVATED No Yes
10006 IGN FIRING FLAG No Yes
10007 IGN PICKUPS OK No Yes
10008 IGN ENGINE ROTATING No Yes
10009 spare
10010 spare
10011 spare
10012 ONE STEP ACTIVE NOW No Yes
10013 ENERGY LEVEL E1 NOW No Yes
10014 ENERGY LEVEL E2 NOW No Yes
10015 ENERGY LEVEL E3 NOW No Yes
10016 MULTI STRIKE NOW No Yes
10017 FAULT NO GEAR TOOTH SIGNAL OK Fault
10018 FAULT NO MAGNETIC RESET SIGNAL OK Fault
10019 FAULT NO CYCLE RESET SIGNAL OK Fault
10020 FAULT WRONG NUMBER OF TEETH OK Fault
10021 FAULT OVERSPEED SHUTDOWN OK Fault
10022 spare
10023 spare
10024 FAULT FIRMWARE CHECKSUM ERR OK Fault
10025 spare
10026 spare
10027 spare
10028 spare
10029 WARN 4-20 LOOP OUT OF RANGE OK Warning
