CPU-95EVS OI 7-13
All rights reserved © ALTRONIC, LLC 2013
49
Register Label 0 1 Notes
10245 WARN HI FROM ENGINE ( N2) OK Warning
10246 WARN LO VOLTAGE ( N2) OK Warning
10247 WARN SHORTED PRIMARY ( N2) OK Warning
10248 WARN OPEN PRIMARY ( N2) OK Warning
10249 –
10256
RESERVED
Enhanced Display Modbus Register 30000
Register Label Units Size (bits) Min Max Notes
30001 ENGINE RPM 1 RPM/bit 16 READ ONLY
30002 MAX SEEN RPM 10 RPM/bit 16 READ ONLY
30003 OVERSPEED SETTING 10 RPM/bit 16 READ ONLY
30004 FAULT GEAR TEETH COUNTS counts 16 READ ONLY
30005 4-20 ANALOG INPUT 0.098mA/bit 16 READ ONLY
30006 COUNTS TO DEGREES SCALER - 16 READ ONLY
30007 GLOBAL TIMING DISPLAY VALUE - 16 READ ONLY
30008 MANUAL RETARD SETTING - 16 READ ONLY
30009 ONESTEP RETARD SETTING - 16 READ ONLY
30010 ANALOG RETARD FROM TABLE - 16 READ ONLY
30011 RPM RETARD FROM TABLE - 16 READ ONLY
30012 SERIAL RETARD FROM REMOTE - 16 READ ONLY
30013 MAX INDIVIDUAL OFFSET - 16 READ ONLY
30014 STANDARD INDIVIDUAL OFFSET - 16 READ ONLY
30015 REFERENCE ANGLE OF RESET PIN 16 READ ONLY
30016 NUMBER OF CYLINDERS - 16 READ ONLY
30017 ENGINE AVERAGE DIAG - 16 READ ONLY
30018 LO SPARK DIAG THRESHOLD - 16 READ ONLY
30019 HI SPARK DIAG THRESHOLD - 16 READ ONLY
30020 NO SPARK DIAG THRESHOLD - 16 READ ONLY
30021 LO FROM ENGINE THRESHOLD - 16 READ ONLY
30022 HI FROM ENGINE THRESHOLD - 16 READ ONLY
30023 RESERVED - 16 0 65535
30024 E2 ENABLE THRESHOLD - 16 READ ONLY
30025 E2 DISABLE HYSTERISIS - 16 READ ONLY
30026 E3 ENABLE THRESHOLD - 16 READ ONLY
30027 E3 DISABLE HYSTERISIS - 16 READ ONLY
30028 CYL TIMING OFFSET (A,A,A1) - 16 READ ONLY
30029 CYL TIMING OFFSET (B,B,A2) - 16 READ ONLY
30030 CYL TIMING OFFSET (C,C,B1) - 16 READ ONLY
30031 CYL TIMING OFFSET (D,D,B2) - 16 READ ONLY
30032 CYL TIMING OFFSET (E,E,C1) - 16 READ ONLY
30033 CYL TIMING OFFSET (F,F,C2) - 16 READ ONLY
30034 CYL TIMING OFFSET (K,G,D1) - 16 READ ONLY
