51
Register Label Units Size (bits) Min Max Notes
30078 DIAG OFFSET (P,M,F1) - 16 READ ONLY
30079 DIAG OFFSET (R,N,F2) - 16 READ ONLY
30080 DIAG OFFSET (S,P,K1) - 16 READ ONLY
30081 DIAG OFFSET (T,R,K2) - 16 READ ONLY
30082 DIAG OFFSET (U,S,L1) - 16 READ ONLY
30083 DIAG OFFSET (V,T,L2) - 16 READ ONLY
30084 DIAG OFFSET ( U,M1) - 16 READ ONLY
30085 DIAG OFFSET ( V,M2) - 16 READ ONLY
30086 DIAG OFFSET ( N1) - 16 READ ONLY
30087 DIAG OFFSET ( N2) - 16 READ ONLY
30088 COV (A,A,A1) - 16 READ ONLY
30089 COV (B,B,A2) - 16 READ ONLY
30090 COV (C,C,B1) - 16 READ ONLY
30091 COV (D,D,B2) - 16 READ ONLY
30092 COV (E,E,C1) - 16 READ ONLY
30093 C OV ( F,F,C2) - 16 READ ONLY
30094 COV (K,G,D1) - 16 READ ONLY
30095 COV (L,H,D2) - 16 READ ONLY
30096 COV (M,K,E1) - 16 READ ONLY
30097 COV (N,L,E2) - 16 READ ONLY
30098 COV (P,M,F1) - 16 READ ONLY
30099 COV (R,N,F2) - 16 READ ONLY
30100 COV (S,P,K1) - 16 READ ONLY
30101 COV (T,R,K2) - 16 READ ONLY
30102 COV (U,S,L1) - 16 READ ONLY
30103 COV (V,T,L2) - 16 READ ONLY
30104 COV ( U,M1) - 16 READ ONLY
30105 COV ( V,M2) - 16 READ ONLY
30106 COV ( N1) - 16 READ ONLY
30107 COV ( N2) - 16 READ ONLY
30108 –
30127
RESERVED - 16 0 65535
30128 FAULT GEAR TEETH ACTUAL - 16 READ ONLY
30129 4-20 ANALOG INPUT mA * 10 16 READ ONLY
30130 GLOBAL TIMING DISPLAY degrees * 10 16 READ ONLY
30131 MANUAL RETARD SETTING degrees * 10 16 READ ONLY
30132 ONESTEP RETARD SETTING degrees * 10 16 READ ONLY
30133 ANALOG RETARD FROM TBL degrees * 10 16 READ ONLY
30134 RPM RETARD FROM TBL degrees * 10 16 READ ONLY
30135 SERIAL RETARD degrees * 10 16 READ ONLY
30136 REF. ANGLE OF RESET PIN degrees * 10 16 READ ONLY
30137 MAX INDIVIDUAL OFFSET degrees * 10 16 READ ONLY
30138 CYL TIM. OFF. (A,A,A1) degrees * 10 16 READ ONLY
