ALTRONIC CD200 IGNITION SYSTEM
10.12 PURGE COUNTER:
During a startup, indicates the number of purge cycles remaining
before the outputs are activated.
10.13 SUPPLY VOLTAGE:
Indicates the measured DC voltage supply level to the CD200.
10.14 SPARK REF. (A, B, C, ETC.):
Indicates the current spark reference number for each cylinder.
10.15 SYNCING:
 Whenred,indicatesthatenginerotationhasbeensensedandthe
synchronization process is taking place.
10.16 INSYNC1:
 Whenred,indicatesthattheindexinputhasbeenrecognizedonce.
10.17 INSYNC2:
 Whenred,indicatesthattheindexhasbeenrecognizeda second
time and the ignition is ready to proceed.
10.18 PURGING:
 Whenred,indicatesthatsynchronizationhasbeencompletedand
the purge cycle countdown is taking place.
10.19 TRYING:
 Whenred,indicatesthattheCD200istryingtoreoutputs,buta
proper primary discharge event has not yet occurred.
10.20 FIRING:
 Whenred,indicatesthatCD200issuccessfullyringprimaryoutputs.
10.21 LOCKOUT:
 Whenred,indicatesthatringsarelockedoutuntilenginerotation
has ceased for a minimum of 5 seconds.
10.22 CRANKING:
 Whenred,indicatesenginerotationbelowtheRunSpeedsetting.
10.23 RUNNING:
 Whenred,indicatesenginerotationabovetheRunSpeedsetting.
10.24 DISC ERROR:
 Whenred,indicatesthattheTestDiscstatusagisactivatedand
thetimingdiscpatternbeingsenseddidnotmatchtheDISCTYPE
selected.
10.25 G-LEAD:
 Whenred,indicatesthattheG-leadisgrounded.
10.26 REMOTE:
 Whenred,indicatesaremoteserialshutdowncommandisactive.
