Altronics CD200 User Manual

FORM CD200 II 5-07
12
INSTALLATION INSTRUCTIONS
10.27 SD-LEAD:
 Whenred,indicatesthatashutdownhasoccurredwhichwasthe
resultofagroundedG-leadcondition.
10.28 SD-REMOTE:
 Whenred,indicatesthatashutdownhasoccurredasaresultofa
remote serial shutdown command.
10.29 SD-OVERSPEED:
 Whenred,indicatesthatashutdownhasoccurredasaresultofthe
engine reaching the Overspeed setting.
10.30 WDOG1:
 When red, indicates that the microprocessor has re-booted since
the ignition has been powered-up.
10.31 WDOG2:
 Whenred,indicatesthatthemicroprocessoriscurrentlyre-boot-
ing.Disregardtherstblinkwhenrstconnecting.
10.32 CHKSUM:
 Whenred,indicatesamicroprocessorchecksumerror.
10.33 LOW VOLT:
 Whenred,indicatesthattheinputDCvoltageisatorbelowtheLow
Voltage setting input.
10.34 NO CHARGE:
 Whenred,indicatesthattheprimarystoragecapacitorhasfailedto
charge properly within the last ~2 seconds.
10.35 PRIMARY OPEN:
 Whenred,indicatesthatanopenprimaryconditionhasbeende-
tected within the last ~2 seconds.
10.36 PRIMARY SHORT:
 Whenred,indicatesthatashortedprimaryconditionhasbeende-
tected within the last ~2 seconds.
10.37 SECONDARY OPEN:
 Whenred,indicatesthatanopensecondaryconditionhasbeende-
tected within the last ~2 seconds.
10.38 CRANKS LOG:
Indicates the total number of crank attempts seen by the CD200.
10.39 STARTS LOG:
Indicates the total number of successful starts seen by the CD200
asdenedbytheRunSpeedsettinginput.
10.40 CYCLE LOG:
Total number of engine cycles seen by the CD200.
