FORM CD200 II 5-07
8
INSTALLATION INSTRUCTIONS
9.11
RUN SPEED SETTING:
Thisnumericentryconguresthetransitionspeedfromcranktorun.
ThissettingalsodeterminesthetransitionofthediagnosticLEDon
theCD200fromcranktorunmodes.Defaultsetting=500RPM.
9.12
LOW VOLTAGE SETTING:
Thisnumericentryconguresthethresholdforthelowvoltagedi-
agnostic of the DC input voltage to the CD200. If the DC voltage de-
creasestothissetting,thediagnosticLEDontheCD200willblink
theappropriatecode.TheCD200willcontinuetotrytoreoutputs
regardlessofthevoltage.Defaultsetting=6volts.
9.13
ENABLE LED DIAGNOSTICS FLAG:
WhenthisLEDstatusagisactivated,theblinkcodediagnosticsfor
primary and secondary outputs are enabled. Default setting is ON.
9.14
SWITCH CAL:
Thesenumericentriescongurethetimingretardforeachposition
ofthemanualtimingswitchontheCD200case.Entryrangeis0to
25.5 degrees of engine retard. The active entry is indicated in blue.
Default setting is 7-6-5-4-3-2-1. If two degrees change per switch
position is desired, enter 14-12-10-8-6-4-2.
9.15
LOOP CAL:
Thesenumericentriesconguretheinterpolatedlookuptablefor
the ignition retard versus the analog current loop input signal. This
allows the operator to create custom spark timing maps versus the
currentloopinputsignal.Entryrangeis0to25.5degreesofengine
retard. The active entries are indicated in blue. Default sequence is
0 degrees retard at 4 mA, 16 degrees retard at 20 mA.
9.16
RPM CAL:
Thesenumericentriesconguretheinterpolatedlookuptablefor
retard versus the engine speed. This allows the operator to create
customsparktimingmapsversusenginerpm.Entryrangeis0to
25.5 degrees of engine retard. The active entries are indicated in
blue. Default sequence is 6 degrees retard at 0 RPM, decreasing to
0 degrees retard at 600 RPM.
9.17
CYLINDER CAL:
These numeric entries congure the amount of individual offset
timing retard added to the global timing for each individual output.
This feature can be used to map an evenly spaced timing disc to an
oddringangleenginepattern.Entryrangeis0to50degreesof
engine retard. Default settings are 0. Contact the factory for further
details of this feature.
