13.4 8 READ/WRITE CONFIGURATION BITS
SUPPORTS WRITE SINGLE ONLY
READABLE IN MULTIPLES OF 8 BITS
STARTING AT 8BIT BOUNDARIES
ADDRESS FUNCTION
00001 DISK ON CAM=0 CRANK=1
00002 TEST FOR PROPER DISK YES=1
00003 ENABLE SECONDARY DIAGS YES=1
00004 ENERGY BIT0 00=
~
160 01=
~
170
00005 ENERGY BIT1 10=
~
180 11=
~
190
00006 SLAVE
00007 reserved
00008 reserved
13.5 4 READ/WRITE REGISTERS MIRROR COIL BITS
ADDRESS FUNCTION
40001 REG40001=CoilBits 00016-00001
40002 REG40002=CoilBits 00032-00017
40003 REG40003=CoilBits 00048-00033
40004 REG40004=CoilBits 00064-00049
13.6 8 READ/WRITE REGISTERS REGARDING APPLICATION
ADDRESS FUNCTION
40005 Disk+1 2,3,4,5,6,7,8,9,10,12
40006 Disk Lineup to TDC xx.x DEG
40007 Insertion Ret MIN=2.0 DEG xx.x
40008 Purge Delay Cycles 0-255
40009 RPM Over Speed Setpoint
40010 RPM Crank to Run Threshold
40011 Low Supply Voltage Limit xx.xV
40012 SLAVE ANGLE xx.x DEG
