SYSTEM OPERATION
11
Where the air inl-
tration rate of a structure is known, the minimum required volume
shall be determined as follows:
(1) For appliances other than fan-assisted, calculate using the following
equation:
21 ft
3
I
other
Required Volume
other
> ________ _________
ACH 1000 Btu/hr
(2) For fan-assisted appliances, calculate using the following equation:
15 ft
3
I
fan
Required Volume
fan
> ________ _________
ACH 1000 Btu/hr
where:
I
other
= all appliances other than fan-assisted input in Btu per hour
I
fan
= fan-assisted appliances input in Btu per hour
ACH = air change per hour (percent of volume of space exchanged
per hour, expressed as a decimal)
(3) Forpurposesofthiscalculation,aninltrationrategreaterthan0.60
ACHshallnotbeusedintheequationsin9.3.2.2(1)and9.3.2.2(2).
9.3.2.3 Indoor Opening Size and Location. Openings used to connect
indoor spaces shall be sized and located in accordance with the following:
(1)* Combining spaces on the same story. Each opening shall have a min-
imumfreeareaof1in.
2
/1000Btu/hr (2200 mm
2
/kW) of the total input
ratingofallappliancesinthespacebutnotlessthan100in.
2
(0.60m
2
).
Oneopeningshallcommencewithin12in.(300mm)ofthetop,and
oneopeningshallcommencewithin12in.(300mm)ofthebottom,
of the enclosure [see Figure A.9.3.2.3(1)]. The minimum dimension
ofairopeningsshallbenotlessthan3in.(80mm).
Furnace
Water
Heater
Opening
Chimney or Gas Vent
Opening








(2) Combining spaces in dierent stories. The volumes of spaces in
dierentstoriesshallbeconsideredascommunicatingspaceswhere
suchspacesareconnectedbyoneormoreopeningsindoorsoroors
havingatotalminimumfreeareaof2in.
2
/1000 Btu/hr (4400 mm
2
/
kW)oftotalinputratingofallappliances.
9.3.3 Outdoor Combustion Air. Outdoor combustion air shall be pro-
vided through opening(s) to the outdoors in accordance with the methods
in9.3.3.1or9.3.3.2.Theminimumdimensionofairopeningsshallnotbe
lessthan3in.(80mm).
9.3.3.1 Two Permanent Openings Method. Two permanent openings,
onecommencingwithin12in.(300mm)ofthetopandonecommencing
within12in.(300mm)ofthebottom,oftheenclosureshallbeprovided.
The openings shall communicate directly, or by ducts, with the outdoors
or spaces that freely communicate with the outdoors, as follows:
(1)* Where directly communicating with the outdoors or where communi-
cating to the outdoors through vertical ducts, each opening shall have a
minimumfreeareaof1in.
2
/4000 Btu/hr (550 min
2
/kW) of total input
ratingofallappliancesintheenclosure.[See Figure A.9.3.3.1(1)(a)
and Figure A.9.3.3.1(1)(b).]
Furnace
Water
Heater
Outlet Air
Chimney or Gas Vent



the


Inlet Air
Ventilation louvers for
unheated crawl space
Alternate
air inlet
Ventilation louvers
(each end of attic)


to Ventilated Attic.
Furnace
Water
Heater
Outlet Air
Chimney or Gas Vent



the


Inlet air duct
[ends 1 ft (300 mm)
above floor]
Ventilation louvers
(each end of attic)

From Outdoors through Ventilated Attic.
(2)* Where communicating with the outdoors through horizontal ducts, each
openingshallhaveaminimumfreeareaof1in.
2
/2000 Btu/hr (1100
min
2
/kW)oftotalinputratingofallappliancesintheenclosure.[See
Figure A.9.3.3.1(2).]
