Amana PHD**C Service Instructions

ACCESSORIES
12
SUPPLY
RETURN
14
24 3/8
47
35
14
14
1
2
42 3/8
12
UNIT SUPPORT
INSULATED PLATFORM
PRC08A ROOF CURB
A
J
B
C
D
E
F
G
1.00"
H
OVER/UNDER DUCT TRANSITION
AMAN
A
®
BRAND
MODEL
"A" DIM "B" DIM "C" DIM "D" DIM "E" DIM "F" DIM "G" DIM "H" DIM "J" DIM
PDTROU4A 42" 26 7/16" 12" 26 1/4" 15" 6 7/8" 20 11/16" 9/16" 9/16"
PDTROU6
A
42" 32" 12" 39 1/2" 15" 10" 20 11/16" 1" 9/16"
PDTROU4A
PDTROU6A
Duct Transition
Over/Under
Converts existing side by side duct connections to over/under ductwork.
(For replacement purposes. The Amana® brand's preceding units had
over/under ducts.)
