Always apply a liquid sealing agent (e.g. Hylomar SQ32M) to sealing
surfaces marked with this symbol.
ü The pump set has been positioned on a level surface.
ü The pump set is secured against tipping over.
1. Remove screw plug 903.46 and joint ring 411.46.
2. Connect the pump set to the power supply.
CAUTION
Pump set running dry
Increased vibrations!
Damage to mechanical seals and bearings!
▷ Never operate the pump set for more than 60seconds outside the fluid to be
handled.
3. Start up the pump set.
4. Fill in grease via lubricating nipple 636.02.
5. Disconnect the pump set from the power supply again and make sure it cannot
be started unintentionally.
6. Close screw plug 903.46 with joint ring 411.46 again.
